1. Please read the instructions carefully before use
2. Optical fiber and debris of the fiber are very fine, sharp at the tip, please adopt a special container for fiber debris collection to prevent fiber debris from pricking the skin or entering into the eyes.
3. Do not disassemble the cleaver, if repair is required, please contact the after-sales person of the manufacturer.
Specifications
Applicable fiber | Single-core silica optical fiber Ribbon fiber(special fiber holder) |
Applicable fiber coating-layer diameter | φ0.25/φ0.9/φ3.0/3.0*2.0mm |
Applicable fiber diameter | 125μm |
Cleaved fiber length | 9-24mm |
Dimensions | 85(W)x75(D)x45(H)mm |
Weight | 205g |
Cleaving angle | ≤0.6° |
Blade life | 48000times |
