Features
1s boot up, 6s splicing, 18s heating.
Stable performance, average splicing loss 0.02dB.
Automatic ARC calibration, easy for maintaining.
Inductive automatic heater, industrial quad-core CPU.
Big capacity battery, more than 250 cycles splicing and heating.
Specifications
Applicable fiber | SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655) |
Diameter of cladding | 80-150μm |
Diameter of coating | 160-900μm |
Typical splice loss | SM: 0.02dB, MM: 0.01dB, DS: 0.04dB, NZDS: 0.04dB |
Return loss | ＞ 60dB |
Fiber cleaved length | 10-16mm (coating diameter＜250um) 16mm (coating diameter:250-1000um) |
Splicing program | 40 groups |
Operate mode | Automatic/Manual |
Auto-heating | Available |
Typical splicing time | 6 seconds |
Typical heating time | 18 seconds |
Fiber magnification | 250X (X or Y view), 125X (X and Y view) |
Display screen | 4.3-inch color LCD monitor |
Records storage | 4000 results |
Loss evaluation | Available |
Tension test | 1.8-2.2N |
Interface | GUI menu interface, easy for operation. |
Battery | 5200mAh Li-battery, typical 250 cycles splicing and heating. |
Power supply | Adapter, input: AC 100-240V(50/50HZ), output: 11-13.5V |
Electrodes life | More than 4000 ARC discharges, can be replaced conveniently. |
Terminal | USB2.0 port, for software upgrading and records exporting. |
Operating conditions | Altitude: 0-5000m, Humidity: 0-95%, Temperature: -10℃~+50℃, Wind speed: Max 15m/s |
Dimension | 149mm(L) *120mm(W) *127mm(H) |
Weight | 1.90kg (including battery) |
