Features
Full digital processing technology, auto core to core alignment.
9 seconds splicing, 28 seconds heating
300X fiber magnification
Simultaneous X and Y view, or X/Y view
Multi alignment mode: cladding alignment, core alignment.
Storing 5000 splice results
Storing electrode discharge times
USB support data transfer
3.7 inches high resolution color LCD screen
The new gloppy cover with nice appearance provide more dust-proof & wind-proof
User-friendly operating system, smart menu design
Battery capacity indication and auto power off in low battery
9000mAh high-capacity Li-Battery
Specifications
Applicable Fibers | SM, MM, DS, NZDS,BIF&UBIF(G.657) |
Average Splice Loss | 0.02dB(SM), 0.01dB(MM), 0.04dB(DS), 0.04dB(NZDS) |
Return Loss | ≥60dB |
Operating mode | Full automatic , semi-automatic |
Typical Average Splice Loss | 0.01 dB with SM, 0.01 dB with MM, 0.03dB with DS, 0.03 dB with NZDS |
Splicing Time | SM FAST mode - 5 seconds; Stander mode -7 seconds:Auto mode-7 seconds |
Storage of Splice Result | 200 images,10,000splice data results to be stored in the internal memory |
Fiber Display | X or Y, both X and Y simultaneously. Front or rear monitor display options with automated image orientation |
Magnification | X or Y:380 X ; X and Y: 270X |
Monitor | 5.0 inch touch screen color LCD display |
Operating Condition | 0 to 5,000 m above sea level, 0 to 95%RH and -10 to 50°C /Max wind velocity of 15M/S |
Return loss | >60dB |
Pull | 1.96-2.09N |
Electrode life | 6000 arc discharges |
Size & Weight | 128(W)*154(D)*130(H)mm, 2.2kgs with BU-16 battery,1.9kgs without battery |
