Features
Standard: In conformity to IEEE 802.3 10 Base-T standard.
In conformity to IEEE 802.3u 100 Base-TX/FX standard.
Built in 128Kb RAM for data buffer.
Back pressure flow control for full duplex; IEEE802.3 X and half duplex.
Automatic identification of MDI/MDI-X cross line.
Forward 1600 bytes packets for management. Can also reach 9k bytes (optional, Must inform us ahead).
Supports link fault pass through function.
Supports far end fault function.
Fiber connector:Choice from SC,ST,FC or LC connector for multi mode and single mode.
Built in a watchdog timer to monitor internal switch error.
LED display for link/activity,full/half,10M/100M.
Transmission distance can reach 2km for multi mode and 120KM for single mode.
Support 4KV lighting protection(external power supply,Optional).Can be rack mounted in 2U 14 slots chassis(external power supply).

Specifications
