Features
User self-calibration function
Comfortable LCD display and optional backlight LCD display supports night operation
Power measurements in dBm or mw and insertion loss in dB
Low battery consumption, more than 240 hours continual operation time for three 1.5V alkaline batteries.
10 minutes Auto-off function can be activated or deactivated.
Applications
Maintenance in Telecom
Maintenance CATV
Fiber Optic Lab Testing
Other Fiber Optic Measurements
Specifications
Type | FFS308A | FFS308B |
Wavelength (nm) | 800~1700nm | |
Detector | InGaAs | |
Measurement Range (dBm) | -70~+3 | -50~+26 |
Uncertainty | ±5% | |
Calibrated Wavelength (nm) | 850,980,1300,1310,1490,1550 | |
Resolution (dB) | 0.01 | |
Optical Connector | FC (interchangeable SC, ST) as well as 2.5mm universal | |
Power Supply | Alkaline Battery (3 AA 1.5V batteries) | |
Battery Operating Time | 240 h with 1.5V Battery (3) | |
Operating Temperature (℃) | -10 ~ +60 | |
Storage Temperature (℃) | -25 ~ +70 | |
Relative Humidity | 0 to 95% (non-condensing) | |
Dimension (mm) | 175x82x33 | |
Weight (g) | 310 | |
