Features

Keep optical transmission performance of optical fiber

Provide safe protection to optical fiber splicing

Easily use and avoid any damage to the optical fiber during installation

Clear sleeve makes it easy to detect splice before shrinkage

Sealing structure provides good performance to the splicing in the environment with temperature and humidity

Fiber Optic Fusion Splice Sleeve Operating Temperature: -45-100℃

Fiber Optic Splice Sleeves Shrinking Temperature Range: 90 - 110℃

Fiber Optic Splice Sleeve Technical Datas

Properties                             Test Method                        Typical Data

Tensile Strength(Mpa)        ASTM D 2671                             18

Ultimate Elongation            ASTM D 2671                            700

Density(g/cm2)                     ISO R1183D                             0.94

Dielectric Strength (KV/mm)   IEC243                                   20

Dielectric Constant                   IEC243                                   2.5

Longitudinal Change             ASTM D 2671                            5
