Features

Keep optical transmission performance of optical fiber

Provide safe protection to optical fiber splicing

Easily use and avoid any damage to the optical fiber during installation

Clear sleeve makes it easy to detect splice before shrinkage

Sealing structure provides good performance to the splicing in the environment with temperature and humidity

Ribbon Fiber Optic Splice Sleeve Operating Temperature: -45~100℃

Ribbon Fiber Optic Splice Sleeves Shrinking Temperature Range: 90 ~ 110℃

Ribbon Fiber Optic Splice Protection Sleeves Technical Datas

Properties                                Test Method                 Typical Data

Tensile Strength(Mpa)               ASTM D 2671                     18

Ultimate Elongation (%)             ASTM D 2671                    700

Density(g/cm2)                         ISO R1183D                         0.94

Dielectric Strength (KV/mm)          IEC243                            20

Dielectric Constant                        IEC243                             2.5

Longitudinal Change (%)            ASTM D 2671                     5
