Features
Metal case, Rugged and durable
Low battery indication, to avoid leakage and wrong judgment
ESD protection design, Protect the LD effectively
Integrated case, to avoid the case intermediate broken
Re-changeable ceramic tube, to avoid returning to manufacturer for this small fault
Long battery life, up to 60 hours＠1mW
Specifications
Central Wavelength | 650nm±10nm (635nm can be required on request) |
Emitter Type | FP-LD |
Output Power (mw) | 1, 10, 20, 30, 50 |
Optical Connector | 2.5mm universal connector For 1.25mm connectors, FC (Male)-LC (Female) convertor can be optional on customer’s requests |
Operating Model | Both CW and Pulse available |
Pulse Frequency | 2~3Hz |
Power Supply | 2 AA alkaline batteries |
Battery Operating Time | 650nm@1mw ≥65hours 650nm@10mw≥15hours Test with Panasonic LR6 AA ALKALINE battery |
Operating Temperature (℃) | -10~+45 |
Storage Temperature (℃) | -40~+70 |
Dimension (mm) | ￠15X210 |
Weight(g) | 120(Without battery) |
